Over 40 electrical code & design calculators for working professionals !
Electrical Wiring Pro v5.1play.google.com.electricalpro&hl
Over 40 Useful Electrical Calculators & Tools, each of which could be an app
in its own right.
For Electricians, Power Engineers and other Electrical Professionals.
Written by a working Electrician using it on a daily basis.
Calculations per National Electrical Code 2005, 2008 and 2011.
NEW Residential/Load Calculations
- Single Family Dwelling
- Multi Family Dwelling
- Range Calculations
- Send results via email for verification and documentation
- Wire Size -> Ampacity
- Ampacity Needed -> Wire Size
- Voltage Drop -> Wire Size
- Dwelling Service Size
- GEC Size
- EGC Size
- New Ampacity section includes
- Improved user interface,
- NEC 2005, 2008 and 2011 (the updates are accounted for by the app)
- > 700 locations with Ambient Temps
- Box Size from Wires / Devices
- Box Size from Cables / Devices
- Standard Box and Typical Plaster Ring INfo
- Pull Box Sizing
- Wires -> Conduit Size Needed
- Wires/Conduit -> % full
- Maximum Wires/Conduit
- Conduit Size Details
- Wire Size Details
- Standard and Rolled Offsets
- Parallel Offsets
- 3-point Saddle
- Round and rectangular corner obstacles
- Segment Bends
- Minimum Bend Radius One-Shot/Full Shoe or Other bends
- Required voltage or % drop -> Wire Size
- Voltage Drop Calculation
- Maximum Length for voltage or % drop
- Maximum Load for voltage or % drop
- Impedance given wire length
- FLC, Wire, Breaker, Heater, Starter, Conduit etc. Sizing
- Locked Rotor Current
- KVAR Capacitor Correction
- NEMA Motor Dimensions
- Basic Transformer Sizing
- Overcurrent Protection Device Sizing
- Transformer Faults
- Delta-Wye configuration
- Standard Receptacle configurations
- AWG-Metric wire size comparison
- Ethernet TIA-568A/B Color Codes
- RJ 11/14/25 Color Codes
- Resistor Color Codes
- In-Foot <-> Metric, Construction Fraction <-> Decimal converter
- Parallel Load Calculator
- Pire Wheel / Ohms Law
- Cover Depth
- Temperature Conversion for 8 different scales
What's in this version : (Updated : Mar 15, 2012)
- 5.1 adds Single- and Multi- Familly Dwelling Load Calcs; Foot-Inch<>Metric and Fraction<>Decimal Converter, Rolling Offsets, Parallel Offsets, Round or Square Corner Obstacles, Segment Bending and much more.
- 5.0 adds Single Phase Receptacles
Required Android O/S : 1.6+
